Water curtain dust collectors, also known as wet dust collectors or water film dust collectors, are air pollution control devices that use water to capture and remove particulate matter from air or gas. They achieve the purpose of dust removal by contacting dust-laden gas with water, causing dust particles to combine with water droplets, and then separating these dust-laden water droplets from the airflow.

Features

1. It can effectively remove liquid and solid particles with a diameter of 0.1-20μm from the airflow, and can also remove some gaseous pollutants.

2. It has high dust removal efficiency and is not easy to generate secondary dust.

3. It is suitable for processing high-temperature and high-humidity gases. Especially for flammable and explosive dust, it has high safety.

4. It has a simple structure and small footprint; it is easy to operate and maintain.

Working Principle

Dust-laden gas entry: Dust-laden gas enters the dust collector.

Water mist or water film formation: Water mist or water film is formed inside the dust collector through a spray device or a special structure.

Dust capture: Dust-laden gas is fully in contact with water mist or water film, and dust particles are wetted and captured by water droplets.

Separation: Dust-laden water droplets are separated from the air flow due to gravity or centrifugal force and settle to the bottom of the dust collector.

Purified gas discharge: Purified gas is discharged from the top of the dust collector.

Slurry treatment: Dust-laden water that settles to the bottom of the dust collector forms slurry, which needs to be cleaned and treated regularly.

Technical Parameters

Equipment precautions:

Choose the appropriate type of dust collector according to the nature of the treated gas and the characteristics of the dust.

Reasonably design the spray system to ensure the uniformity and coverage of the water mist or water film.

Clean the inside of the dust collector regularly to prevent clogging and scaling.

Treat the wastewater and discharge it in compliance with the standards.

Take good anti-corrosion measures to extend the service life of the equipment.

Water curtain dust collectors have become the main equipment choice for low and medium concentration dust control due to their economy and adaptability. However, the machine model needs to be matched according to the scenario (such as corrosiveness and particle fineness) and combined with subsequent water treatment measures to meet environmental protection requirements.
